Powering Tomorrow’s Fabrication: Integrated Machinery Lines from Water Heaters to Cylinders

A dive into the full-suite production solutions: solar and electric water heater lines, LPG/LNG cylinder systems, coatings, shearing, and presses—all engineered and automated to scale.

Solar and Electric Water Heater Production Lines

Modern water heater tank lines converge deep drawing, trimming, seam welding, coating, and assembly. Handling stainless or galvanized steel (0.31–0.5 mm), they fabricate inner and outer tanks with precision and speed.

These lines include hydraulic blanking, deep drawing presses, oval- or flanged expansion stations, trimming/joggling, seam welding (both longitudinal and circumferential), followed by packing and cleaning modules.

Up to hundreds of tanks per shift can be produced. Seam welding is done via automatic TIG or MIG systems—some even come with dual-torch circumferential options. Coating lines then apply enamel powder or wet spray coats with ovens and curing tunnels.

AIR-ENERGY HEAT PUMP accessory systems like foam filling or flexible conveyor lines integrate cleanly into these lines.

H2: LPG & LNG Cylinder Machinery Lines

These heavy-duty gas cylinder production lines begin with deep drawing for body and dish ends, followed by trimming, hole punching, bead forming, shot blasting, seam welding, coating, and rigorous pressure testing.

Key modules:

• Deep drawing hydraulic press

• Trimming & joggle machines

• Flanging and hole-punching stations

• Shot blasting and surface cleaning units

• Seam welding using laser-guided MIG or TIG (often dual-seam)

• Enamel powder coating lines and curing ovens

• Pressure testing with helium mass spectrometers and leak detectors

• Packing and cleaning conveyors

These lines offer short cycle times, high throughput, and stringent safety controls. Tailored for anti-corrosion, strength testing, and fully automated assembly.

Specialized Production Equipment

Special Equipment for Transformers

This includes dedicated PLC-controlled winding lines, insulation tank welding, oil-tank forming, and core processing equipment with full traceability and precision calibration.

Fiber Laser Cutting

Single- and exchange-platform fiber laser cutters equipped for stainless and galvanized steel sheet cutting to tight tolerances—ideal for precision panel blanking and tooling.

Expansion & Fire-Extinguisher Cylinder Lines

Dedicated metal forming, welding, and coating stations tailored to expansion tanks and extinguisher vessel fabrication.

Surface Preparation & Coating Technology

Shot Blast Machines

Designed for LPG/LNG cylinders and pipe surfaces—automatic blasting chambers with high-speed impellers clean rust, scale, and residual casting flash to SA2.5–3.0 finish.

Enamel Powder Coating Lines

Enamel or powder spray booths and curing ovens optimized for water heater outer shells and gas cylinders. These guarantee adhesion and corrosion resistance with even coating layers.

Surface spray lines may integrate automated handling systems, spray robots, and inline ovens for consistent results.

Hydraulic & CNC Shearing & Press Lines

These integrate hydraulic and CNC shearing for sheet blanking, followed by deep drawing and trimming.
Hydraulic deep-drawing presses shaped for large-diameter tanks, transfer lines, foam injection machines, and pressing stations support full automation in both water heater and cylinder Fabrication.

Multi-ton presses (63 T–2500 T) are used for drawing, hot pressing, composite pressing, and forming of cookware, filter ends, transformer parts, or ballistic panels.

Packing, Cleaning, & Final Assembly Automation

Automated packing lines include conveyors, ultrasonic cleaning stations, foam- or water rinsers, and electrostatic packaging stations.
Electric water heater accessory assembly units include foam injection, necking, welding, valve insertion, and final QC modules.

These integrated flows minimize human touchpoints—ideal for hygienic or high-volume industrial applications.

Workflow Integration & Modular Design

Line designs follow an assembly line logic: shearing → drawing → trimming → welding → surface prep → coating → inspection → final assembly.
Each module connects via flexible conveyor lines or vacuum conveyors with PLC-level integration. Quality checkpoints like weld seam tracking, HI pressure testing, helium leak detectors, and RFID tracking ensure total traceability.

Modular design allows scaling: add coating ovens, foam lines, or testing stations as needed.

Why Choose These Integrated Production Lines?

• High Yield Throughput: Hundreds to thousands of units per day.

• Automation & Consistency: PLC, laser tracking, dual-torch welding, robotic feeding.

• Full Compliance: ISO, CE, safety, and pressure standard testing like helium, hydrostatic, and many certifications.

• Flexible Compatibility: Adaptable to varying tank diameters (310–600 mm, or up to φ850 mm for LNG), gusset forms, or diameter profiles.

Challenges & Solutions

• Precision Welding: Laser-guided MIG or TIG seam welding ensures ≤ 2 mm reinforcement and ≥ 90% first-pass yield.

• Surface Finish Consistency: Automated shot blasting before coating helps to meet adhesion standards and strengthen metal toughness.

• Material Handling: Robots and conveyors reduce labor and contamination risk.

• Quality Traceability: Pressure testing and RFID-based tagging integrated end-to-end.

Case Study Highlights

A plant producing LPG cylinders managed to produce 500 sets daily using an integrated line including drawing, beading, seam welding with laser tracking, shot blasting, enamel coating, and leak testing.

A solar water heater facility ramped up production by 70% by integrating automatic blanking, hydraulic presses, TIG welding, foam filling, seam welding, and powder coating, with 24/7 unmanned runs.

The Future of Fabrication Automation

• Smart AI-Based QC: Real-time camera inspection, arc monitoring and defect detection to flag deviations.

• Energy Recovery in Heat Ovens: Reusing waste heat in curing lines to reduce energy consumption.

• Hybrid Laser-MIG Welding: Achieves deeper penetration, faster cycle times.

• Material Innovations: Move to stainless, aluminum composite, and high-strength steel—requiring adaptive welding and coating strategies.

Contact & Consultation

Think about future-proofing your production. These machinery lines are modular and scalable. From solar heater tanks to LPG/LNG cylinders or precision deep‑drawn parts, integrated automation transforms output.

📞 HM: Leon Machinery WhatsApp: +86 181 3677 3114
📧 Email: leonxu0317@gmail.com
